! ======= CONFIGURATION NETTOYÉE ET COMMENTÉE =======
                version 17.6
                service timestamps debug uptime
                service timestamps log datetime
                service password-encryption
                service call-home
                platform punt-keepalive disable-kernel-core

                hostname SWITCH-CLEANED ! Nom anonymisé

                ! ======= VRF de management =======
                vrf definition Mgmt-vrf
                 address-family ipv4
                 exit-address-family
                 address-family ipv6
                 exit-address-family

                no logging console

                ! ======= Sécurité des accès (mots de passe supprimés) =======
                enable secret 9

                aaa new-model
                aaa authentication login default local
                aaa session-id common

                boot system switch all flash:packages.conf
                switch 1 provision c9200l-24p-4x

                vtp mode transparent

                ip name-server x.x.x.x
                ip domain name exemple.local

                login on-success log
                authentication mac-move permit

                ! ======= Certificats (tronqués ici pour la lisibilité) =======
                ! crypto pki trustpoints...

                ! ======= Licence =======
                license boot level network-essentials addon dna-essentials

                diagnostic bootup level minimal

                ! ======= Spanning Tree en mode MST =======
                spanning-tree mode mst
                spanning-tree extend system-id
                spanning-tree mst configuration
                 name MST-EXEMPLE
                 revision 2

                memory free low-watermark processor 10308

                ! ======= Utilisateur local =======
                username admin privilege 15 secret 9

                redundancy
                 mode sso

                lldp timer 5
                lldp run

                ! ======= VLANs ANONYMISÉS =======
                vlan 1
                 name VLAN-DATA
                vlan 2
                 name VLAN-VOIP
                vlan 3
                 name VLAN-COPIEUR
                vlan 4
                 name VLAN-WIFI
                vlan 5
                 name VLAN-MANAGEMENT

                ! ======= INTERFACES PHYSIQUES =======
                interface range GigabitEthernet1/0/1 - 1/0/20
                 switchport access vlan 1
                 switchport mode access
                 switchport voice vlan 2
                 spanning-tree portfast
                 spanning-tree bpduguard enable

                interface range GigabitEthernet1/0/21 - 1/0/22
                 description COPIEUR
                 switchport access vlan 3
                 switchport mode access
                 spanning-tree bpduguard enable

                interface GigabitEthernet1/0/23
                 description WIFI
                 switchport trunk native vlan 4
                 switchport trunk allowed vlan 2-4
                 switchport mode trunk

                interface GigabitEthernet1/0/24
                 description ONDULEUR
                 switchport access vlan 5
                 switchport mode access
                 spanning-tree bpduguard enable

                ! ======= INTERFACES UP-LINKS 10G =======
                interface TenGigabitEthernet1/1/1
                 description LIAISON-UPLINK-1
                 switchport mode trunk

                interface TenGigabitEthernet1/1/2
                 description LIAISON-UPLINK-2
                 switchport mode trunk

                ! Interfaces 1/1/3 et 1/1/4 non utilisées
                interface TenGigabitEthernet1/1/3
                !
                interface TenGigabitEthernet1/1/4
                !

                ! ======= INTERFACES VLAN =======
                interface Vlan1
                 no ip address
                 shutdown

                interface Vlan5
                 ip address x.x.x.x 255.255.255.0 ! IP anonymisée

                ! ======= ROUTAGE DE BASE =======
                ip default-gateway x.x.x.254
                ip forward-protocol nd
                no ip http server
                ip http authentication local
                ip http secure-server
                ip ssh time-out 60
                ip ssh authentication-retries 2
                ip ssh version 2

                ip sla responder

                ! ======= LOGS & SNMP =======
                logging host x.x.x.x
                snmp-server community  RO
                snmp mib flash cache

                ! ======= PLAN DE CONTRÔLE =======
                control-plane
                 service-policy input system-cpp-policy

                ! ======= CONSOLE, AUX & VTY =======
                line con 0
                 stopbits 1

                line vty 0 4
                 transport input ssh

                line vty 5 15
                 session-timeout 120
                 password 7
                 transport input ssh

                ! ======= NTP =======
                ntp server x.x.x.x

                ! ======= CALL-HOME =======
                call-home
                 contact-email-addr sch-smart-licensing@cisco.com
                 profile "CiscoTAC-1"
                  active
                  destination transport-method http

                end
